Placing the mouse pointer on the image will launch the image amplifier and you can easily see the extra product detail
SDS Plus Flat Tip
Electric Hammer Drill Bits
Manufacturing Process: Atmosphere controlled hardening, tempering and brazing.

Materials: Good quality steel shanks and the Tungsten Carbide Tips.

Diameter : Ø 4.0mm--- 28.0mm, Total Length: 110-1000mm.

Features: Drill bits that work harder, for longer.

* Multi-carbide tip technology, combined with precision machining, delivers increased strength and extended life.

* Professional blasting and finishing reduces drill fatigue and increases the strength of the bit.

* Double flute geometry of the body gives maximum resistance to extreme torsion levels and maximizes speed and penetration rates.

Application:
* Ideal for Brick work / Concrete / Block work / other masonry, Also suitable for Wood / Plastic / Ceramic / Tiles / Light building materials.

* Fits hammer drills with SDS-Plus chucking and 2-slot chucking system. It can be used with Electric Hammer of BOSCH Co., AEG. Co., BLACK & DECKER Co., HILTI Co., PHILLIPS Co., HITACHI Co., and MAKITA Co., The shank is round with dual-arc and dual-key way.

Item No.
Diameter ( mm )
Overall Length ( mm )
Flute Length ( mm )
MT004110
4
110mm
45mm
MT004160
4
160mm
95mm
MT005110
5
110mm
45mm
MT005160
5
160mm
95mm
MT005210
5
210mm
147mm
MT005310
5
310mm
247mm
MT006110
6
110mm
45mm
MT006160
6
160mm
97mm
MT006210
6
210mm
147mm
MT006260
6
260mm
197mm
MT006460
6
460mm
397mm
MT008110
8
110mm
45mm
MT008160
8
160mm
97mm
MT008210
8
210mm
147mm
MT008260
8
260mm
197mm
MT008310
8
310mm
247mm
MT008460
8
460mm
397mm
MT008610
8
610mm
545mm
MT010110
10
110mm
45mm
MT010160
10
160mm
97mm
MT010210
10
210mm
147mm
MT010260
10
260mm
197mm
MT010310
10
310mm
247mm
MT010360
10
360mm
297mm
MT010460
10
460mm
397mm
MT010600
10
600mm
537mm
MT0101000
10
1000mm
937mm
MT012160
12
160mm
85mm
MT012210
12
210mm
135mm
MT012260
12
260mm
185mm
MT012310
12
310mm
235mm
MT012460
12
460mm
385mm
MT012600
12
600mm
525mm
MT0121000
12
1000mm
920mm
MT014160
14
160mm
80mm
MT014200
14
200mm
120mm
MT014260
14
260mm
180mm
MT014300
14
300mm
220mm
MT014460
14
460mm
380mm
MT014600
14
600mm
520mm
MT0141000
14
1000mm
920mm
MT015160
15
160mm
80mm
MT015200
15
200mm
120mm
MT015260
15
260mm
180mm
MT015460
15
460mm
380mm
MT016160
16
160mm
80mm
MT016200
16
200mm
120mm
MT016250
16
250mm
180mm
MT016300
16
300mm
230mm
MT016460
16
460mm
380mm
MT016600
16
600mm
520mm
MT016800
16
800mm
720mm
